The helm station is fitted with four 24-inch touchscreen displays and is

equipped with the integrated Simrad Command System, which controls
the main propulsion, navigation, monitoring and home automation functions

using the same interface, simplifying yacht management and navigation.

1. ENGINES
SIDE VIEW
2 x MTU 16V 2000 M86 power 2217mhp / 1630kW at 2450 rpm std
2 x MTU 16V 2000 M96L power 2638mhp / 1939kW at 2450 rpm opt
2. SPEED (knots) MTU 2200 MTU 2638
Maximum speed 24 28
Cruising speed 20 24
3. RANGE (nautical miles) MTU 2200 MTU 2638
Maximum speed 270 240
Cruising speed 310 280
4. MAIN SIZES
Loa = overall length (standard ISO 8666) 30,13 m 98 ft. 10 in.
Lh = Hull length (standard ISO 8666) 23,98 m 78 ft. 8 in.
Lwl = waterline length (boat fully laden) 22,31 m 73 ft. 2 in.
Maximum beam 6,81 m 22 ft. 4 in.
Depth under propellers (boat fully laden) 2,29 m 7 ft. 6 in.
Displacement unladen 98 ton/lb 216053
Displacement laden 111 ton/lb 244713
Maximum number of person on board 20
Design category Directive 2013/53/EU A
Certification modules B + F + Aa RINA S.p.A.
(Sound Emission)
5. TECHNICAL DATA
Hull type: warped hull with spray rails and deadrise 12 °
H = Overall height from keel 10,81 m 35 ft. 6 in.
P = pulpit + transom 6,15 m 20 ft. 2 in.
Fuel tank capacity 9000 lt/US gals 2378
Water tanks capacity 1320 lt/US gals 349

6. PERFORMANCE SPECIFICATIONS
overloading the yacht by 2 ton/lb 4409
top speed decreases of 1 knot

the performance is estimated at the following conditions: 103 ton/lb 227605
standard version displacement of the yacht
at 1/3 of load, clean hull, 25°C air temperature,
good weather conditions, 8 persons on board
